| Material | Stainless Steel 304 |
| Water Inlet Diameter | DN65 |
| Nozzle Diameter | DN50 |
| Size (mm) | L240*W420*H740 |
| Total Weight | 37kg |
| Upper Dimension Reduction Ratio | 1:10 |
| Lower Dimension Reduction Ratio | 1:10 |
| Stepping Motor Working Voltage | AC55V-70V |
| The Power Of The Stepper Motor | 200W |
| The Number Of Phases Of The Stepper Motor | Two Phase |
| Upper Stepping Motor Maximum Torque | 8.5(N.M) |
| Lower Stepping Motor Maximum Torque | 12(N.M) |
| Sensor Voltage | DC24V |
| Upper (Lower) Dimensional Sensor Line Color Separation | Brown-24v Blue-Gnd Yellow-Return To Zero Signal |
| Upper (Lower) Dimensional Stepper Motor Line Color Separation | Red-A+ Green-A- Yellow-B+ Black-B- |
| Recommended Stepper Motor Mounting Cables | JHS 4*2.5mm² |
| Recommended Sensor Mounting Cable | PVVP 3*1.0mm² |
| Number Of Built-In Slip Ring Lines | 7 |
| Running Angle | 360° |
Material
304 stainless steel construction.
Nozzles
Multi-directional drive, suitable for different nozzle types.
Applicable Water Environment
For fresh- and pool water.
Swing Angle
Nozzle part – Rotation range above the water surface up to 180°. Upper dimensional part – rotation angle up to 360°.
Structure
The conductive slip ring is built into the equipment.
