| Maximum rotating diameter of nozzle | Φ800mm |
| Equipment size | L380*W480*H500 |
| Operating voltage | DC60-90V |
| Power of the whole machine | 300W |
| Number of motor phases | 2 |
| Step angle | 1.8° |
| Rated phase current | 6.0A |
| Phase resistance | 0.52Ω±10% |
| Phase inductance | 7.0mH±20% |
| Reduction ratio | 1:10 |
| Equipment torque | 85N.m |
| Sensor voltage | DC24V |
| Rotor inertia | 3600g.cm² |
| Electrical insulation resistance | 100MΩ(500VDC) |
| Temperature rise | 80K |
| Insulation class | IP68 |
| Environmental temperature | Environmental temperature |
| Water temperature | 0-35°C |
Material
304 stainless steel construction.
Nozzles
Multi-directional drive, suitable for different nozzle types.
Applicable Water Environment
For fresh- and pool water.
Swing Angle
Rotation range above the water surface up to 120°.
Structure
The 4mm plate bending process is used to enhance the overall stability of the equipment.
Cost Savings
The equipment’s main power source and control (internal control board, drive, switching power supply) are integrated, which reduces the cost of cables, control cabinets, and control rooms for customers.
Lighting Integration
The integrated DMX512 lighting device allows the light to better follow the water column. Compared with conventional CNC equipment, the Multi-directional Drive 1D/DMX512 can better reflect the perfect combination of water and light.
