| Model | S | M | L | XL |
| Material | Stainless Steel 304 | Stainless Steel 304 | Stainless Steel 304 | Stainless Steel 304 |
| Net Weight (KG) | 7 | 12.6 | 14 | 23.3 |
| Rectifier Barrel Size (mm) | L220*W200*H300 | L270*W260*H380 | L400*W310*H480 | L400*W370*H500 |
| Packing Size (mm) | L270*W250*H350 | L320*W310*H430 | L450*W360*H530 | L450*W420*H550 |
| Water Outlet (mm) | 10 | 14 | 16 | 18 |
| Water Intake | DN25 | DN40 | DN40 | DN40 |
| Flow Rate (M3/H) | 3 | 4 | 5 | 7 |
| Lift (m) | 4 | 10 | 12 | 14 |
| Span (m) | 2.0 | 3.0 | 4.7 | 5.5 |
| Spray Height (m) | 2.0 | 2.2 | 2.8 | 3.0 |
| Standard Built-in Light | 3W/Monochrome | 3W/Monochrome | 3W/Monochrome | 3W/Monochrome |
Material
304 stainless steel construction.
Water Shape
The precision nozzle creates an excellent glass-like effect. Stable dynamic parabola
Applicable Water Environment
For fresh- and pool water.
Lighting Device
Built-in LED lighting can pass through the entire water column.
Operating Noise
No vibration & low noise, also suitable for indoor.
Controlled Method
Can be controlled and programmed through DMX, PLC, and fountain software.
High Precision
Precise landing point, clear water column.
